What is Biomass Gasification?
Biomass gasification is the process of converting organic materials into combustible gases, called syngas, which is then used to produce electricity. The 800kW Biomass Gas Generator Set leverages this advanced technology, providing an eco-friendly power generation option for industries seeking sustainable solutions.
How Biomass Gasification Works:
Fuel Feedstock: Organic waste like wood chips, agricultural residue, or other biomass sources are fed into the gasifier.
Gasification Process: The feedstock undergoes high-temperature treatment to create syngas, which is a mixture of gases such as carbon monoxide, hydrogen, and methane.
Power Generation: The syngas is used to fuel the engine, which drives the generator to produce electricity.
This clean, renewable energy source can significantly reduce operational costs and carbon emissions.
Applications of the 800kW Biomass Gas Generator Set
The 800kW Biomass Gas Generator Set is suitable for a wide range of industrial applications. Here are some common uses:
Large-scale Industrial Operations: Perfect for manufacturing plants, factories, and production facilities that require high power output.
Agricultural and Forestry Industries: Ideal for farms, agricultural operations, and timber processing plants looking to convert waste products into energy.
Waste Management Facilities: Biomass from landfills or urban waste can be used to generate electricity, reducing waste and helping with energy needs.
District Heating Systems: In addition to electricity generation, the heat produced can be used for district heating or industrial heating needs.
Off-Grid Energy Solutions: Ideal for remote areas or industries looking for an independent, renewable power solution.
Key Advantages of the 800kW Biomass Gas Generator Set
The 800kW Biomass Gas Generator Set offers several distinct advantages:
Renewable Energy Source: Biomass is a sustainable, carbon-neutral fuel, contributing to a cleaner environment.
High Power Output: Capable of delivering 800kW, suitable for larger industrial applications such as manufacturing plants, food processing facilities, and more.
Cost-Effective: Biomass is often a more affordable fuel option compared to traditional fossil fuels, especially in regions with an abundant supply of organic waste.
Flexibility in Fuel: It can utilize a variety of feedstocks, such as wood chips, agricultural waste, and other organic materials, ensuring a reliable and cost-efficient fuel supply.
Low Emissions: Biomass gasifiers have lower CO2 emissions compared to fossil-fuel-powered generators, helping businesses meet environmental standards and reduce their carbon footprint.
Long-Term Durability: Built with high-quality materials, the 800kW generator is designed to last, even under demanding industrial conditions.
Main technical features
Shunt Intake and Turbocharging Technology：
That means gas and air will be isolated with no contact to eliminate the generation of mixed gas before entering the cylinder. At the same time, the exhaust energy of the genset is used to turbocharge the gas and air respectively, which realizes the improvement of intake and the synchronous improvement of operation power and volume power and ensures safety operation.
Since 2018, it has been running safely and steadily for more than 30000 hours. The measured electric efficiency is more than 40%, that is, one cubic meter of exhaust gas generates one kilowatt-hour of electricity. There is no carbon monoxide leakage, no backfire and flash explosion, and the genset runs smoothly. Self consumption rate is less than 2%. The operation control of the genset is automatically adjusted with the change of gas.
Main technical parameters
800kW biomass generator technical parameters:
| Engine Model | CP21H |
| Alternator Model |
| 800-6/6300 | 800-6/ 10500 |
| Control System Model |
| MCU2-SE4 |
| Rated Power | kW | 800 |
| Rated Current | A | 91.6 | 55 |
| Rated Voltage | V | 6300 | 10500 |
| Rated Frequency | Hz | 50 |
| Rated Speed | r/min | 1000 |
| Rated Power Factor | cosφ | 0.8(Lagging) |
| Oil Consumption | g/(kW · h) | ≤0.5 |
| Electric Efficiency | % | 40 |
| Performance Grade | G2 |
| Phase Number and Connection Method | Three-phase three-wire or three-phase four-wire |
| Voltage Regulating Mode | Automatic |
| exciting mode | Brushless Excitation |
| Starting Mode | DC24V DC motor or AC380V AC motor |
| Speed Regulating Mode | Electric Speed Regulating |
| Noise | dB（A） | ≤107 | 85(Containerized) |
| Vibration | mm/s | ≤7.2 |
| Dimensions | (L×B×H) ,mm | 6810×1740×2490 | 11000×3000×3000 |
| Net Weight | kg | 14000 | 23000 |
| Overhaul | h | 40000 |
Environmental Impact and Sustainability
Biomass energy is one of the cleanest forms of renewable energy, offering numerous environmental benefits:
Carbon Neutral: Biomass is considered a carbon-neutral fuel since the CO2 emitted during combustion is offset by the CO2 absorbed by plants during their growth.
Waste Reduction: By converting organic waste into energy, biomass generators help reduce landfill waste, providing an efficient waste management solution.
Reduction in Greenhouse Gas Emissions: Compared to traditional fossil fuels, biomass significantly reduces the emission of greenhouse gases like CO2, NOx, and sulfur dioxide (SO2).
Sustainable Resource: Biomass is a renewable resource, ensuring a consistent and long-term supply of fuel without depleting natural resources.
This makes the 800kW Biomass Gas Generator Set a perfect choice for businesses aiming to reduce their environmental impact while improving energy security.
Why Choose Our 800kW Biomass Gas Generator Set?
Here’s why our 800kW Biomass Gas Generator Set stands out in the market:
Proven Technology: Our biomass generators are backed by years of research and development, providing you with reliable, cutting-edge technology.
Cost-Efficient Operations: Biomass is one of the most cost-effective renewable fuels, helping you save on energy costs in the long run.
High Performance: With high power output and fuel efficiency, our biomass generators are perfect for medium to large-scale industrial applications.
Customized Solutions: We provide tailored solutions to meet your specific energy needs, ensuring the best performance for your business.
After-Sales Support: Our expert technicians provide comprehensive after-sales services, including installation, maintenance, and troubleshooting.
Conclusion: Sustainable Power for a Greener Future
The 800kW Biomass Gas Generator Set is an excellent investment for businesses looking to harness renewable energy from organic waste materials. With its high efficiency, low environmental impact, and flexible fuel options, this generator is ideal for industries seeking to reduce energy costs while promoting sustainability.
