What is Biomass Gasification?
Biomass gasification is a process where organic materials, such as wood chips, agricultural waste, and other biomass feedstocks, are converted into syngas (synthesis gas). The syngas produced fuels the 800kW Silent Type Biomass Gas Generator Set, which generates electricity in a clean and sustainable manner.
Biomass Gasification Process:
Fuel Input: Biomass feedstock is fed into the gasifier, where it undergoes high-temperature treatment.
Gasification: The heat breaks down the biomass to produce syngas, a mixture of carbon monoxide, hydrogen, and methane.
Electricity Generation: The syngas powers the engine, which drives the generator to produce electricity.
This process enables businesses to generate energy from renewable, carbon-neutral resources while also reducing waste.
Key Benefits of the 800kW Silent Type Biomass Gas Generator Set
The 800kW Silent Type Biomass Gas Generator Set offers multiple advantages over traditional power generation systems:
Reduced Noise Emissions: This generator is specifically designed for quiet operation, making it ideal for locations with strict noise regulations such as residential areas, hospitals, and urban environments.
Sustainable Power Generation: Biomass is a renewable energy source that helps businesses reduce their carbon footprint while providing reliable power.
Lower Operating Costs: Biomass fuel is generally more affordable than fossil fuels, which leads to lower operating costs in the long run.
Flexibility in Fuel Supply: The generator can run on a wide variety of biomass feedstocks, including wood chips, agricultural waste, and organic materials.
Low Environmental Impact: Biomass gasification reduces greenhouse gas emissions and particulate matter compared to fossil fuel generators.
Durability and Reliability: Designed to perform reliably in harsh environments, ensuring a long service life with minimal downtime.
Main technical features
Shunt Intake and Turbocharging Technology：
That means gas and air will be isolated with no contact to eliminate the generation of mixed gas before entering the cylinder. At the same time, the exhaust energy of the genset is used to turbocharge the gas and air respectively, which realizes the improvement of intake and the synchronous improvement of operation power and volume power and ensures safety operation.
Since 2018, it has been running safely and steadily for more than 30000 hours. The measured electric efficiency is more than 40%, that is, one cubic meter of exhaust gas generates one kilowatt-hour of electricity. There is no carbon monoxide leakage, no backfire and flash explosion, and the genset runs smoothly. Self consumption rate is less than 2%. The operation control of the genset is automatically adjusted with the change of gas.
Main technical parameters
800kW Silent type biomass generator technical parameters:
| Engine Model | CP21H |
| Alternator Model |
| 800-6/6300 | 800-6/ 10500 |
| Control System Model |
| MCU2-SE4 |
| Rated Power | kW | 800 |
| Rated Current | A | 91.6 | 55 |
| Rated Voltage | V | 6300 | 10500 |
| Rated Frequency | Hz | 50 |
| Rated Speed | r/min | 1000 |
| Rated Power Factor | cosφ | 0.8(Lagging) |
| Oil Consumption | g/(kW · h) | ≤0.5 |
| Electric Efficiency | % | 40 |
| Performance Grade | G2 |
| Phase Number and Connection Method | Three-phase three-wire or three-phase four-wire |
| Voltage Regulating Mode | Automatic |
| exciting mode | Brushless Excitation |
| Starting Mode | DC24V DC motor or AC380V AC motor |
| Speed Regulating Mode | Electric Speed Regulating |
| Noise | dB（A） | ≤107 | 85(Containerized) |
| Vibration | mm/s | ≤7.2 |
| Dimensions | (L×W×H) mm | 6810×1740×2490 | 11000×3000×3000 |
| Net Weight | kg | 14000 | 23000 |
| Overhaul | h | 40000 |
Applications of the 800kW Silent Type Biomass Gas Generator Set
The 800kW Silent Type Biomass Gas Generator Set is suitable for a wide range of applications:
Industrial Power Generation: Ideal for manufacturing plants, factories, and other large-scale industrial operations requiring reliable and clean electricity.
Remote Areas: Perfect for off-grid applications where access to the main power grid is unavailable or unreliable.
Agricultural Operations: Biomass feedstocks like crop residues, wood chips, and other organic materials are readily available in agricultural areas, making this generator a perfect fit.
Waste-to-Energy Solutions: Converts organic waste into electricity, making it an excellent solution for municipalities, landfills, and waste management companies.
District Heating Systems: The heat generated by the biomass generator can be used to provide district heating for residential or commercial buildings.
Silent Operation Technology
One of the standout features of the 800kW Silent Type Biomass Gas Generator Set is its ability to operate quietly without compromising performance. The silent operation is made possible by a series of advanced technologies and design features:
Key Silent Operation Features:
Soundproof Enclosure: The generator set is housed in a specially designed soundproof enclosure that significantly reduces noise emissions.
Vibration Dampening: Shock-absorbing mounts are used to minimize mechanical vibrations, further decreasing noise levels.
Advanced Exhaust System: The exhaust system is engineered to reduce noise while maintaining high power output.
This makes the 800kW Silent Type Biomass Gas Generator Set an excellent choice for noise-sensitive environments such as urban areas, hospitals, and commercial properties.
Environmental Impact and Sustainability
The 800kW Silent Type Biomass Gas Generator Set is a sustainable energy solution with significant environmental benefits:
Carbon-Neutral Power Generation: Biomass is considered carbon-neutral because the carbon dioxide released during combustion is offset by the carbon dioxide absorbed by the plants during their growth cycle.
Lower Emissions: Biomass generators produce far fewer emissions than conventional diesel or gas-powered generators, including a reduction in carbon dioxide (CO2), nitrogen oxides (NOx), and particulate matter.
Waste Reduction: This generator provides a way to turn agricultural, forestry, and other organic waste into usable energy, reducing waste sent to landfills.
Renewable Fuel Source: Biomass is a renewable resource, ensuring a continuous supply of fuel without depleting finite resources.
The 800kW Silent Type Biomass Gas Generator Set helps businesses contribute to sustainability goals while offering clean, efficient power generation.
Why Choose the 800kW Silent Type Biomass Gas Generator Set?
The 800kW Silent Type Biomass Gas Generator Set stands out in the market for its combination of silent operation, sustainability, and cost-efficiency:
Silent Operation: Ideal for noise-sensitive locations, reducing environmental noise pollution.
Renewable Energy Source: Utilizes biomass, a renewable energy resource, helping businesses achieve their sustainability goals.
Cost-Effective: Biomass is typically more affordable than fossil fuels, offering long-term cost savings.
Environmental Impact: Lowers CO2 emissions, particulate matter, and other harmful pollutants compared to traditional generators.
Reliability: Designed for maximum reliability and durability in various environmental conditions.
Flexible and Customizable: Can be tailored to meet specific power and fuel requirements, ensuring efficiency and optimal performance.
Conclusion: Clean, Quiet, and Sustainable Power
The 800kW Silent Type Biomass Gas Generator Set is the perfect solution for businesses looking for reliable, clean, and cost-effective power generation in noise-sensitive environments. By utilizing renewable biomass, this generator provides a green energy alternative that not only meets your energy needs but also helps you reduce emissions and promote sustainability.
Investing in the 800kW Silent Type Biomass Gas Generator Set ensures that your business stays powered while supporting a cleaner, more sustainable future.
