What is Biomass Gasification?
Biomass gasification is the process of converting organic materials, such as agricultural residues or wood chips, into syngas, a mixture of gases like carbon monoxide, hydrogen, and methane. The 1200kW Biomass Gas Generator Set uses this syngas to generate electricity in an environmentally friendly manner.
How Biomass Gasification Works:
Fuel Feedstock: Biomass feedstocks are loaded into the gasifier.
Gasification Process: The feedstock undergoes a thermochemical process to produce syngas.
Electricity Generation: The syngas powers the engine, which drives the generator to produce electricity.
Biomass gasification is an ideal solution for industries seeking reliable and renewable power sources that help reduce dependency on fossil fuels.
Advantages of the 1200kW Biomass Gas Generator Set
The 1200kW Biomass Gas Generator Set offers several advantages over conventional power generation systems:
High Power Output: With 1200kW of power, this generator is ideal for large-scale industrial operations, such as manufacturing plants, industrial facilities, and commercial businesses.
Renewable and Sustainable: Biomass is a renewable energy source that reduces reliance on fossil fuels and supports carbon-neutral energy production.
Flexible Fuel Options: The generator is capable of running on a variety of feedstocks, including wood chips, agricultural waste, and other organic materials, ensuring a constant and cost-effective supply of fuel.
Low Operating Costs: Biomass is often more affordable than fossil fuels, and the generator’s high efficiency helps reduce overall energy costs.
Environmental Benefits: Biomass gasification has lower CO2 emissions compared to traditional fossil fuel generators, helping businesses meet sustainability goals and comply with emissions regulations.
Reliability and Durability: Built with robust materials and designed for long-term use, the 1200kW Biomass Gas Generator Set offers excellent reliability and minimal downtime.
Main technical features
Shunt Intake and Turbocharging Technology：
That means gas and air will be isolated with no contact to eliminate the generation of mixed gas before entering the cylinder. At the same time, the exhaust energy of the genset is used to turbocharge the gas and air respectively, which realizes the improvement of intake and the synchronous improvement of operation power and volume power and ensures safety operation.
Since 2018, it has been running safely and steadily for more than 30000 hours. The measured electric efficiency is more than 40%, that is, one cubic meter of exhaust gas generates one kilowatt-hour of electricity. There is no carbon monoxide leakage, no backfire and flash explosion, and the genset runs smoothly. Self consumption rate is less than 2%. The operation control of the genset is automatically adjusted with the change of gas.
Main technical parameters
1200kW biomass generator technical parameters:
| Engine Model | CP22H |
| Alternator Model |
| 1200-6/6300 | 1200-6/ 10500 |
| Control System Model | MCU2-SE4 |
| Rated Power | kW | 1200 |
| Rated Current | A | 137.5 | 82.5 |
| Rated Voltage | V | 6300 | 10500 |
| Rated Frequency | Hz | 50 |
| Rated Speed | r/min | 1000 |
| Rated Power Factor | cosφ | 0.8(Lagging) |
| Oil Consumption | g/(kW · h) | ≤0.5 |
| Electric Efficiency | % | 40 |
| Performance Grade | G2 |
| Phase Number and Connection Method | Three-phase three-wire or three-phase four-wire |
| Voltage Regulating Mode | Automatic |
| exciting mode | Brushless Excitation |
| Starting Mode | Dual Electric Motor Starting |
| Speed Regulating Mode | Electric Speed Regulating |
| Noise | dB（A） | ≤107 | 85( Containerized) |
| Vibration | mm/s | ≤7.2 |
| Dimensions | (L×B×H),mm | 7536×1822×2325 | 13200×3000×2900 |
| Net Weight | kg | 18900 | 30000 |
| Overhaul | h | 40000 |
Applications of the 1200kW Biomass Gas Generator Set
The 1200kW Biomass Gas Generator Set is suitable for a range of industrial and commercial applications, including:
Large-Scale Industrial Operations: Ideal for factories, manufacturing plants, and other large facilities that require a significant amount of power.
Agricultural and Forestry Industries: Biomass from farms, forests, and timber mills can be converted into electricity, reducing energy costs and improving sustainability.
Waste Management Facilities: Organic waste from landfills and municipal solid waste can be used as fuel to generate electricity, providing a green waste-to-energy solution.
District Heating Systems: The heat produced by the generator can be used for district heating applications, providing energy-efficient heating solutions for residential and commercial areas.
Off-Grid Energy Solutions: Ideal for remote or off-grid locations that need an independent, renewable power supply.
Environmental Impact and Sustainability
The 1200kW Biomass Gas Generator Set is a sustainable solution for reducing greenhouse gas emissions and promoting clean energy generation:
Carbon-Neutral Energy: Biomass is considered carbon-neutral because the CO2 emissions from burning biomass are offset by the CO2 absorbed by the plants during their growth.
Reduction in Greenhouse Gas Emissions: Compared to fossil fuel generators, biomass generators produce significantly lower levels of CO2, NOx, and particulate matter.
Waste Reduction: Biomass generators help reduce waste by converting agricultural, forestry, and municipal waste into valuable electricity.
Renewable Energy Source: Biomass is a renewable resource, ensuring a continuous fuel supply without depleting natural resources.
This makes the 1200kW Biomass Gas Generator Set an environmentally friendly alternative to traditional power generation methods.
Why Choose Our 1200kW Biomass Gas Generator Set?
Our 1200kW Biomass Gas Generator Set stands out as a top choice for businesses looking for sustainable and reliable power generation. Here’s why:
Proven Technology: Our biomass generators are based on years of experience and advanced technology, ensuring high performance and reliability.
Cost-Efficient: By utilizing renewable biomass fuel, this generator offers long-term savings on energy costs compared to conventional fossil fuel generators.
Environmentally Friendly: This generator set helps businesses meet sustainability goals by reducing emissions and utilizing renewable energy sources.
Customizable Solutions: We offer tailored solutions to meet your specific energy needs, whether you're in agriculture, manufacturing, or another industry.
Comprehensive Support: Our expert team provides installation, training, and ongoing maintenance support to ensure optimal performance.
Conclusion: Sustainable Power for a Greener Future
The 1200kW Biomass Gas Generator Set is an excellent solution for large-scale industrial and commercial operations seeking to reduce energy costs, lower emissions, and promote sustainability. With its high efficiency, renewable fuel options, and environmental benefits, this generator is an ideal choice for businesses that want to improve their energy security while contributing to a cleaner, greener future.
