What is Biomass Gasification?
Biomass gasification is a process that converts organic materials like wood chips, agricultural residues, and other biomass feedstocks into syngas (synthesis gas). The syngas, which is a mixture of carbon monoxide, hydrogen, and methane, is then used to fuel the 500kW Silent Type Biomass Gas Generator Set, producing clean electricity and thermal energy.
Biomass Gasification Process:
Fuel Input: Organic materials (biomass) are loaded into the gasifier.
Gasification Reaction: The feedstock undergoes high-temperature treatment to produce syngas.
Electricity Generation: The syngas fuels the generator’s engine, producing electricity.
Biomass gasification is a sustainable and cost-efficient method of producing energy while also reducing waste.
Advantages of the 500kW Silent Type Biomass Gas Generator Set
The 500kW Silent Type Biomass Gas Generator Set offers several key advantages:
Low Noise Emissions: Thanks to its quiet operation design, this generator is perfect for locations with strict noise regulations, such as urban areas, hospitals, and residential neighborhoods.
Renewable and Sustainable: Uses biomass, a renewable fuel source, reducing dependence on fossil fuels and supporting carbon-neutral energy production.
Cost-Effective Power Generation: Biomass is often cheaper than conventional fossil fuels, providing long-term savings on energy costs.
Flexible Fuel Options: Can run on various biomass feedstocks such as wood chips, straw, or agricultural waste, offering flexibility and reducing fuel costs.
Reliable and Durable: Built with high-quality materials, the generator is designed to perform reliably in harsh environments.
Environmental Benefits: Significantly lowers CO2 emissions compared to fossil-fuel generators, helping businesses meet environmental sustainability targets.
Main technical features
Shunt Intake and Turbocharging Technology：
That means gas and air will be isolated with no contact to eliminate the generation of mixed gas before entering the cylinder. At the same time, the exhaust energy of the genset is used to turbocharge the gas and air respectively, which realizes the improvement of intake and the synchronous improvement of operation power and volume power and ensures safety operation.
Since 2018, it has been running safely and steadily for more than 30000 hours. The measured electric efficiency is more than 40%, that is, one cubic meter of exhaust gas generates one kilowatt-hour of electricity. There is no carbon monoxide leakage, no backfire and flash explosion, and the genset runs smoothly. Self consumption rate is less than 2%. The operation control of the genset is automatically adjusted with the change of gas.
Main technical parameters
500kW Silent typebiomass generator technical parameters:
| Unit model | CP500GFJ11 |
| Engine model | 12V190-1B-500 |
| Generator model | 500-6/10500 |
| Control system type | SE3-CP500GFJ11 |
| Rated power, kW | 500 |
| Rated current, A | 34.4 |
| Rated voltage, V | 10500 |
| Rated frequency, Hz | 50 |
| Rated speed, r/min | 1000 |
| Rated power factor, cosφ | 0.8 (Lagging) |
| Generation efficiency, % | 38 |
| Performance level | G2 |
| Number of phases and connection method | Three-phase three-wire or three-phase four-wire |
| Voltage regulation method | Automatic voltage regulation |
| Excitation method | Brushless excitation |
| Starting method | Electric start |
| Speed regulation method | Electronic speed regulation |
| Noise, dB (A) | ≤107 |
| Vibration, mm/s | ≤7.2 |
| Dimensions (L×W×H), mm | 10000×2438×2591 |
| Net mass, kg | 18000 |
| Overhaul period, h | 40000 |
Applications of the 500kW Silent Type Biomass Gas Generator Set
The 500kW Silent Type Biomass Gas Generator Set is suitable for a wide range of applications, particularly in locations where noise reduction is critical:
Commercial and Industrial Use: Perfect for factories, commercial buildings, and industrial parks that need reliable, eco-friendly power.
Remote Locations and Off-Grid Operations: Ideal for areas without access to the main power grid, providing an independent energy source.
Agricultural Applications: Can be used in farms and agricultural facilities where biomass waste such as crop residues can be used as fuel.
Waste-to-Energy Projects: Converts organic waste into energy, reducing landfill waste while generating electricity and heat.
District Heating Systems: The heat generated can be used for district heating or space heating applications.
Silent Operation Technology
One of the standout features of the 500kW Silent Type Biomass Gas Generator Set is its quiet operation. This generator set utilizes advanced noise reduction technologies to ensure it operates at significantly lower noise levels compared to conventional generators.
Silent Operation Features:
Noise Insulation: Equipped with a specially designed soundproof enclosure to reduce engine noise.
Vibration Reduction: Advanced shock-absorbing mounts minimize vibration, further decreasing noise levels.
Low-Noise Exhaust System: A specially engineered exhaust system ensures quieter operation without sacrificing efficiency or performance.
This makes the 500kW Silent Type Biomass Gas Generator Set ideal for urban environments or any situation where noise pollution is a concern.
Environmental Impact and Sustainability
The 500kW Silent Type Biomass Gas Generator Set offers numerous environmental benefits, making it a sustainable choice for businesses looking to reduce their carbon footprint:
Carbon-Neutral Energy: Biomass is considered carbon-neutral because the CO2 emitted during combustion is offset by the CO2 absorbed by the plants during their growth.
Lower Emissions: Compared to traditional fossil fuel-based generators, biomass generators emit significantly less CO2, NOx, and particulate matter.
Waste Reduction: This generator set helps reduce waste by converting agricultural, forestry, and municipal organic waste into valuable energy.
Renewable Fuel Source: Biomass is a renewable and sustainable resource, ensuring that the generator can operate continuously without depleting natural resources.
This makes the 500kW Silent Type Biomass Gas Generator Set an environmentally friendly power generation solution.
Why Choose the 500kW Silent Type Biomass Gas Generator Set?
There are several reasons why the 500kW Silent Type Biomass Gas Generator Set stands out:
Silent Operation: Designed for locations with noise restrictions, providing a quieter alternative to traditional generators.
Cost Savings: Biomass is a low-cost, renewable fuel source that helps businesses save on long-term energy expenses.
Environmental Sustainability: Helps reduce carbon emissions and promotes a cleaner, greener environment.
Long-Term Durability: Built with high-quality components to ensure reliable performance and minimal downtime.
Flexible and Customizable: The generator can be tailored to meet your specific power requirements and fuel availability.
Comprehensive Support: Our team offers installation, maintenance, and troubleshooting services to ensure your generator operates at peak performance.
Conclusion: Quiet, Sustainable Power for a Greener Future
The 500kW Silent Type Biomass Gas Generator Set is an excellent solution for businesses seeking a reliable, cost-effective, and eco-friendly power generation option. With its quiet operation, renewable fuel source, and low emissions, it is ideal for both urban and rural applications. Invest in this generator today to contribute to a greener future and reduce your energy costs.
