1350kW Deutz Biogas Power Plant | 3-Unit V12 Parallel Generator System

1350kw V12 Deutz Biogas generator 3 units in parallel genset

Description

The 1350KW V12 Deutz Biogas Generator Genset, configured with three 450KW units in parallel, offers a flexible and scalable solution for large-scale power generation. By running three units in parallel, this system provides a total output of 1350KW, making it an ideal choice for industrial, agricultural, and waste-to-energy applications. Powered by the robust V12 Deutz engine, known for its efficiency, reliability, and durability, this generator ensures optimal performance and minimal downtime. With biogas as its fuel, this genset contributes to sustainability efforts by reducing greenhouse gas emissions and providing a renewable energy solution that lowers operating costs and dependency on traditional power sources.

Rated power:1350kW;

Rated current:1687.5kVA;

Continuous power: 1215kW;

Frequency:50/60Hz;

Voltage:0.4kV/0.6kV/10.5kV;

Operating noise:95dB(A)/7m;

Methane content:>60%;

Low heat value:Hu ≥ 26.3MJ/Nm;

Gas intake pressure:20Kpa~100Kpa(Configure according to project requirements);

Weight:28500kg;

Deminsions(LxW×H):12192mm×3200mm×4700mm;

This series of units are small in size and can be used and transported in containers. One container can hold 2MW.

They have good sudden load performance, short warm-up time, continuous use efficiency of 90%, and thermal efficiency of up to 40%.

Inquiry Now Add to Cart

Description

Product Features

Triple-Unit Parallel Configuration: The generator operates with three 450KW Deutz V12 engines in parallel, providing a total output of 1350KW. This configuration ensures flexibility, scalability, and redundancy for continuous, reliable power.
Deutz V12 Engine Technology: The V12 Deutz engine is renowned for its high fuel efficiency, low emissions, and long operational life. Its robust design ensures it can handle demanding operational environments with ease.
Biogas Fuel Flexibility: This generator is compatible with a wide range of biogas fuels, including methane from agricultural waste, landfill gas, and other organic waste, offering flexibility in fuel sourcing and contributing to environmental sustainability.
Scalable Energy Solution: The parallel setup allows for easy expansion, enabling you to add more units as power demands grow, making this an ideal choice for businesses with evolving energy needs.
Eco-Friendly and Cost-Effective: Utilizing biogas as fuel, this genset significantly reduces greenhouse gas emissions, helping businesses achieve sustainability goals while lowering operating costs through fuel efficiency and low maintenance requirements.

Product Parameters

AC Alternator data		Gas engine data
Generator Brand	Mecca	Engine Brand	Huachai-Deutz
Motor Model	ECO40 1L4C	Engine Model	HC12V132
Rated Voltage(V)	400	Engine type	V-bank-12 cylinders-turbocharged
Rated Power(H class)kW	450	Cylinder Bore x Stroke(mm)	132mm×145mm
Rated Capacity(H class)kVA	562.5	Displacement (L)	24
Motor efficiency (%)/(400V)	95	Compression ratio	11
Power factor	0.8	Rated output power (single)	535kW-1500rpm/1800rpm
Connection Methods	D/Y	Maximum lubricant consumption (g/kW.h)	＜0.3
Rotor insulation class	H class	Minimum air intake (kg/h)	2200
Rated temperature rise	H class	Ignition method	Electronically controlled single-cylinder independent high-energyignition
Excitation method	Brush-less	Fuel Control Method	Equivalent combustion, closed loop control
Rotation speed (min- 1)	1500/1800	Debugging method	Electronic commissioning
Shell protection grade	IP23	Cooling method	Forced water cooling

Applications

Industrial Applications: Ideal for large-scale industrial operations, such as manufacturing plants, chemical processing, and food processing industries, where a reliable, cost-effective power source is essential.
Agricultural Operations: Perfect for agricultural facilities that produce biogas from organic waste, such as manure, crop residues, and food waste, providing a renewable energy source that reduces reliance on fossil fuels.
Waste-to-Energy Projects: This generator is a perfect fit for waste-to-energy applications, where organic waste is converted into biogas to generate electricity, reducing landfill waste and supporting sustainability.
Off-Grid Locations: Suitable for off-grid areas where a reliable power supply is necessary, including remote farms, industrial plants, or locations with limited access to the main electricity grid.

Environmental Benefits

Reduction of Greenhouse Gas Emissions: By using biogas as fuel, this generator reduces methane emissions, a potent greenhouse gas, helping mitigate climate change and contributing to cleaner air and a healthier environment.
Sustainable Power Generation: The V12 Deutz Biogas Generator utilizes renewable biogas, reducing dependence on non-renewable energy sources and supporting a transition to sustainable energy.
Low Emissions: The engine’s design meets strict international emission standards, ensuring minimal environmental impact while maintaining optimal performance.

Energy Efficiency and Economic Benefits

Fuel Efficiency: The V12 Deutz engine is optimized for high fuel efficiency, ensuring maximum energy output from minimal fuel consumption. This helps reduce operating costs and increase the generator’s overall cost-effectiveness.
High Return on Investment (ROI): Due to its high efficiency and low maintenance costs, this genset provides excellent ROI, making it a cost-effective solution for large-scale power generation.
Long-Term Savings: The generator’s durability, fuel efficiency, and low maintenance requirements ensure long-term operational savings, reducing the need for repairs and downtime over the system’s lifespan.

Frequently Asked Questions (FAQ)

Q: Why are three units used in parallel?

A: The parallel configuration of three 450KW units provides scalability and redundancy. It allows for continuous operation with minimal downtime and makes it easy to increase power output as demand grows.

Q: What types of biogas can be used with this generator?

A: The 1350KW V12 Deutz Biogas Generator is compatible with various types of biogas, including methane from agricultural waste, landfill gas, and other organic waste, providing flexibility in fuel sourcing.

Q: How efficient is the fuel consumption?

A: The V12 Deutz engine is highly fuel-efficient, optimizing fuel usage to reduce overall operational costs. Specific fuel consumption varies depending on the type of biogas used and the operational conditions.

Q: Can the system be expanded in the future?

A: Yes, the parallel configuration allows for easy expansion. Additional units can be added to meet growing energy demands, making this an ideal solution for businesses looking for scalable power generation.
