Scalable 900kW Biogas Power: 2x V12 Deutz Generators in Parallel System

900kw V12 Deutz Biogas generator 2 sets parallel power plant

Description

The 900KW V12 Deutz Biogas Generator Power Plant, configured with two sets in parallel, offers a scalable and highly efficient solution for large-scale power generation using renewable biogas. This system provides a combined output of 900KW, delivering reliable and cost-effective energy for industrial, agricultural, and waste-to-energy applications. Powered by the robust V12 Deutz engine, it ensures outstanding fuel efficiency, long-lasting performance, and minimal maintenance, making it an ideal choice for businesses looking to reduce energy costs while contributing to sustainability goals. The dual-set configuration ensures flexibility in energy production, scalability, and continuous operation with minimal downtime.

Rated power:900kW;

Rated current:1125kVA;

Continuous power: 810kW;

Frequency:50/60Hz;

Voltage:0.4kV/0.6kV/10.5kV;

Operating noise:95dB(A)/7m;

Methane content:>60%;

Low heat value:Hu ≥ 26.3MJ/Nm;

Gas intake pressure:20Kpa~100Kpa(Configure according to project requirements);

Weight:17000kg;

Deminsions(LxW×H):12192mm×2438mm×2591mm;

This series of units are small in size and can be used and transported in containers. One container can hold 2MW.

They have good sudden load performance, short warm-up time, continuous use efficiency of 90%, and thermal efficiency of up to 40%.

Inquiry Now Add to Cart

Description

Product Features

Dual-Set Parallel Configuration: The system consists of two 450KW Deutz engines operating in parallel to deliver a total output of 900KW, providing flexibility, scalability, and redundancy to meet the energy demands of large facilities.
Deutz V12 Engine Technology: Powered by the trusted V12 Deutz engine, known for its superior durability, fuel efficiency, and low maintenance requirements. This engine is built to perform in even the most demanding environments.
Biogas Flexibility: This generator runs on biogas, including methane from agricultural waste, landfill gas, and other organic waste, making it an eco-friendly alternative to traditional fossil fuel-based power generation.
High Scalability: The parallel configuration allows for easy scalability, meaning that additional units can be added to increase capacity as energy demands grow.
Eco-Friendly: By utilizing biogas as fuel, this generator significantly reduces greenhouse gas emissions and helps businesses meet sustainability and carbon reduction targets.
Low Operating Costs: The dual-unit system reduces maintenance needs and optimizes fuel usage, leading to lower overall operating costs over the long term.

Product Parameters

AC Alternator data		Gas engine data
Generator Brand	Mecca	Engine Brand	Huachai-Deutz
Motor Model	ECO40 1.5L4	Engine Model	HC12V132
Rated Voltage(V)	400	Engine type	V-bank-12 cylinders-turbocharged
Rated Power(H class)kW	500	Cylinder Bore x Stroke(mm)	132mm×145mm
Rated Capacity(H class)kVA	625	Displacement (L)	24
Motor efficiency (%)/(400V)	94.2	Compression ratio	11.5
Power factor	0.8	Rated output power (single)	535kW-1500rpm/1800rpm
Connection Methods	D/Y	Maximum lubricant consumption (g/kW.h)	＜0.3
Rotor insulation class	H class	Minimum air intake (kg/h)	2200
Rated temperature rise	F class	Ignition method	Electronically controlled single-cylinder independent high-energyignition
Excitation method	Brush-less	Fuel Control Method	Equivalent combustion, closed loop control
Rotation speed (min- 1)	1500/1800	Debugging method	Electronic commissioning
Shell protection grade	IP23	Cooling method	Forced water cooling

Applications

Industrial Applications: The 900KW V12 Deutz Biogas Generator is perfect for large industrial operations, including manufacturing plants, food processing, chemical production, and more, where high power demand is coupled with the need for sustainable energy.
Agricultural Operations: This system is ideal for agricultural facilities that generate biogas from organic waste such as manure, crop residues, and food waste, providing a reliable and renewable energy source.
Waste-to-Energy Projects: The generator is well-suited for waste-to-energy applications, where organic waste is converted into biogas to generate electricity, helping to reduce landfill waste and support environmental sustainability.
Off-Grid Energy Needs: Ideal for off-grid locations where reliable power generation is needed without relying on the external power grid.

Environmental Benefits

Reduction of Greenhouse Gas Emissions: By utilizing biogas as fuel, the generator helps reduce methane emissions, a potent greenhouse gas, and contributes to climate change mitigation efforts.
Sustainable Power Generation: This system supports the transition to renewable energy by using biogas, a clean and renewable fuel, reducing reliance on fossil fuels and promoting sustainability.
Low Emissions: The Deutz V12 engine meets stringent environmental standards for emissions, ensuring compliance with international regulations and providing cleaner energy production.

Energy Efficiency and Economic Benefits

Cost-Effective Operation: The V12 Deutz Biogas Generator is designed for high fuel efficiency, reducing operating costs and making it a cost-effective energy solution for large facilities.
High ROI: The 900KW generator provides a high return on investment due to its fuel efficiency, minimal maintenance needs, and long service life. The dual-set parallel configuration further enhances system reliability and reduces downtime.
Long-Term Savings: The system’s high efficiency and durability ensure long-term savings, reducing both operational costs and the frequency of maintenance and repairs.

Frequently Asked Questions (FAQ)

Q: Why is the generator configured with two sets in parallel?

A: The dual-set configuration increases system reliability and scalability. It allows for continuous operation with minimal downtime and gives the flexibility to adjust power output based on energy demands.

Q: What types of biogas can be used with this generator?

A: The 900KW Deutz Biogas Generator can operate on a variety of biogas fuels, including methane from agricultural waste, landfill gas, and organic waste, offering flexibility in fuel sourcing.

Q: How efficient is the fuel consumption?

A: The generator is highly fuel-efficient, ensuring long operating hours with minimal fuel consumption. Specific fuel consumption rates depend on the type of biogas used and the operating conditions.

Q: Is the generator suitable for remote or off-grid locations?

A: Yes, this generator is perfect for remote or off-grid locations, including industrial plants, agricultural operations, or waste-to-energy projects that require reliable power generation without access to the power grid.
