Key Features
Rated Output: 800 kW prime power (single unit) – flexible for 50Hz or 60Hz systems.
Fuel Type: Natural gas, offering cleaner combustion, reduced particulate matter and lower operating cost.
Engine Brand: Perkins – a globally recognized engine manufacturer known for durability and reliability.
Single‑Unit Design: All components (engine, alternator, control panel, base frame) in one compact module, easing transport and installation.
High Efficiency: Optimized gas‑engine combustion cycle, minimal heat loss and lower fuel consumption per kW delivered.
Low Emissions: Meets stricter environmental standards and is suitable for locations with emission regulations.
Advanced Control System: Built‑in control panel with digital monitoring, automatic start/stop, fault alarms, and remote communication capability.
Robust Construction: Heavy‑duty skid/base, vibration isolation, industrial‑grade alternator, and full protection for use in demanding environments.
Flexible Configuration: Can be customised for sound‑attenuated enclosure, parallel operation, automatic transfer switches (ATS), and various voltage/frequency options.
Global Support & Service: With Perkins worldwide network and local partners, maintenance and spare‑parts availability is assured.
Features of Perkins units:
1.Highly efficient gas engine.
2.AC synchronous alternator. Gas safety train and gas protection device against leakage.
3.With cooler and Temperature Control System to make sure the unit can work normally at 50℃ environment temperature.
4.Strict shop test for all gensets. Industrial silencer with silencing ability of 12-20dB(A).
5.Advanced engine control system: ECI control system including: ignition system, speed control system , protection system，air/fuel ratio control system.
6.Independent electrical control cabinet for remote control.
7.Multi-functional control system with simple operation.
8.Data communication interfaces integrated into control system.
9.Monitoring battery voltage and charging automatically.
Noted:The product can provide special customization services. If you have any needs, please consult us.
| Item | Details |
| Rated Power | 800kW |
| Rated Current | 625kVA |
| Continuous Power | 800kW |
| Frequency | 50Hz/60Hz |
| Voltage | 0.4kV/0.6kV/10.5kV |
| Operating Noise | 95dB(A) at 7m |
| Methane Content | >85% |
| Low Heat Value | Hu ≥ 31.4MJ/Nm |
| Reference Weight | 5980kg |
| Dimensions (L×W×H) | 4500mm×2200mm×2600mm |
Typical Applications
Industrial Plants & Manufacturing Facilities: Provide reliable backup or main power to critical equipment, ensuring minimal downtime.
Commercial Buildings & Data Centers: High‑capacity generator for large‑scale commercial sites where continuity of power is vital.
Remote / Off‑Grid Sites: Ideal for remote locations with limited grid access, allowing for independent power supply.
Utility & Infrastructure Projects: Use for grid support, peak‑shaving, or as part of combined heat & power (CHP) systems when paired with heat‑recovery modules.
Green Power Transition: Natural‑gas gensets serve as a cleaner bridge technology towards fully renewable energy systems.
Why Choose Perkins Natural Gas Generator?
Brand Reliability: Perkins has decades of experience in heavy‑duty engines and generator sets worldwide and is trusted by OEMs and end‑users alike.
Fuel Economy: Natural gas engine technology provides lower fuel cost per kilowatt hour and lower maintenance burden compared to diesel.
Cleaner Operation: Reduced emissions of NOₓ, CO₂ and particulates make this set easier to deploy in regulated areas or environmentally sensitive sites.
Modular & Scalable: The single‑unit format means quicker commissioning and easier future expansion if needed.
Global Service Infrastructure: With a wide service network, spare parts and support are accessible globally – minimizing downtime and risk.
Remarks
1.Engine Control System: ECI (American brand);
2.Throttle: Bosch (German brand);
3.Spark plug: NGK(Japanese brand);
4.Generator master controller: Comap (Czech brand); DEIF(Danish brand); DSE(England brnad);
5.Altermator: Mecca (Italian brand); Stamford (American brand); Leroy Somer (French brand);
6.Starting mode: electric start;
7.Overhaul period: 36000h~60000h;
8.Generator type: pure copper brushless, automatic voltage regulation;
9.Operation mode: grid-connected/parallel/isolated/automatic control, etc;
Installation, Operation & Maintenance
Site Preparation: Ensure level, firm base, adequate ventilation, proper exhaust routing, gas supply line designed to match engine requirements, and local electrical infrastructure.
Commissioning: Initial run‑in under load, verification of control circuitry, safety shutdowns (low oil, high temperature, over‑speed), grounding and electrical connections.
Routine Maintenance: Regular inspections of gas supply system, filters, lubricants, cooling system, alternator bearings, vibration and noise levels, battery and control module.
Service & Parts: Recommend establishing a service agreement, stocking critical spare parts (filters, sensors, gaskets) and scheduling periodic preventive maintenance to protect investment.
