750kw Steyr Biogas Generator 3units in parallel power plant

750kw Steyr Biogas Generator 3units in parallel power plant

Description

The 750KW Steyr Biogas Generator Power Plant, configured with three units in parallel, provides a scalable, high-efficiency solution for large-scale power generation. This system delivers a combined output of 750KW, offering flexibility and reliability for industrial, agricultural, and waste-to-energy projects. Powered by the proven Steyr engine, the system maximizes fuel efficiency and reduces operating costs while contributing to sustainability goals. Whether you need reliable power for a growing business or a large-scale renewable energy solution, the 750KW Steyr Biogas Generator Power Plant offers exceptional performance and long-term savings.

Rated power:750kw;

Rated current:937kVA;

Continuous power:525kw;

Frequency: 50Hz/60Hz;

Voltage: 0.4kV/0.6kV/10.5kV;

Operating noise:95dB(A)/7m;

Methane content:>50%;

Low heat value:Hu ≥ 21.3MJ/Nm;

Reference Weight: 14500kg;

Dimensions (L×W×H): 10000mm×3000mm×3300mm;

Inquiry Now Add to Cart

Description

Product Features

Triple-Unit Parallel Configuration: The system operates with three 250KW Steyr engines running in parallel, delivering a total power output of 750KW. This parallel configuration ensures flexibility, scalability, and continuous operation with minimal downtime.
Steyr Engine Technology: Powered by the durable and fuel-efficient Steyr engine, known for its high performance and low maintenance needs, this generator guarantees reliable operation even under demanding conditions.
Biogas Fuel Flexibility: The 750KW Steyr Biogas Generator can run on a variety of biogas fuels, including methane from agricultural waste, landfill gas, and organic waste, making it a versatile, renewable energy solution.
Eco-Friendly Operation: By utilizing biogas, this generator significantly reduces greenhouse gas emissions, helping businesses meet sustainability and carbon reduction targets while promoting clean energy production.
High Scalability: The ability to run three units in parallel offers easy scalability. Additional units can be added as power demands grow, making this system a flexible solution for businesses with evolving energy needs.
Low Operating Costs: Designed for high fuel efficiency, the Steyr engine minimizes fuel consumption and reduces maintenance costs, leading to substantial long-term savings.

Product Parameters

AC Alternator data		Gas engine data
Generator Brand	EN	Engine Brand	CNHTC
Motor Model	EN250-1L4C	Engine Model	Steyr T12
Rated Voltage(V)	400	Engine type	Inline 6 cylinders-turbocharged
Rated Power(H class)kW	240	Cylinder Bore x Stroke(mm)	126mm×115mm
Rated Capacity(H class)kVA	300	Displacement (L)	11.6
Motor efficiency (%)/(400V)	93.5	Compression ratio	11
Power factor	0.8	Rated output power (single)	280kW-1500rpm/1800rpm
Connection Methods	D/Y	Maximum lubricant consumption (g/kW.h)	＜0.3
Rotor insulation class	H class	Minimum air intake (kg/h)	1190
Rated temperature rise	H class	Ignition method	Electronically controlled single-cylinder independent high-energyignition
Excitation method	Brush-less	Fuel Control Method	Equivalent combustion, closed loop control
Rotation speed (min- 1)	1500/1800	Debugging method	Electronic commissioning
Shell protection grade	IP23

Applications

Industrial Applications: Perfect for industrial facilities requiring a large, reliable power source. This generator is ideal for manufacturing plants, chemical processing, and other energy-intensive operations.
Agricultural Operations: Ideal for agricultural operations that produce biogas from organic waste, such as manure, crop residues, and food processing waste. It provides a renewable and cost-effective solution for on-site energy generation.
Waste-to-Energy Projects: The 750KW Steyr Biogas Generator is an excellent choice for waste-to-energy projects, where organic waste is converted into clean electricity, reducing landfill waste and supporting sustainable energy production.
Off-Grid Power Generation: This system is perfect for off-grid locations, providing reliable power to remote farms, industrial plants, or facilities with limited access to the electricity grid.

Environmental Benefits

Reduction in Greenhouse Gas Emissions: The system reduces methane emissions, a potent greenhouse gas, by utilizing biogas as a renewable fuel. This helps mitigate climate change and supports environmental sustainability.
Sustainable Power Generation: The 750KW Steyr Biogas Generator uses biogas, a renewable energy source, to provide clean electricity and reduce reliance on fossil fuels, contributing to a more sustainable energy future.
Low Emissions: The Steyr engine is designed to meet international emission standards, ensuring the system operates with minimal environmental impact and complies with stringent regulations.

Energy Efficiency and Economic Benefits

Cost-Effective Operation: The system is designed for high fuel efficiency, ensuring maximum energy output with minimal fuel consumption. This reduces operating costs and makes it a cost-effective energy solution for medium to large-scale operations.
High Return on Investment (ROI): The 750KW Steyr Biogas Generator offers a high ROI due to its fuel efficiency, minimal maintenance needs, and long lifespan. The parallel configuration further enhances system reliability, reducing downtime and increasing overall productivity.
Long-Term Savings: The generator’s low maintenance requirements and high efficiency ensure long-term savings, minimizing operational costs and extending the system's service life.

Frequently Asked Questions (FAQ)

Q: Why is the system configured with three units in parallel?

A: The three-unit parallel configuration provides flexibility, scalability, and redundancy. It ensures continuous operation with minimal downtime and allows businesses to scale up energy production as needed.

Q: What types of biogas can be used with this generator?

A: The 750KW Steyr Biogas Generator can operate on various types of biogas, including methane from agricultural waste, landfill gas, and organic waste, providing a flexible and renewable energy solution.

Q: How efficient is the fuel consumption?

A: The generator is highly fuel-efficient, optimizing fuel use to reduce operational costs. Specific fuel consumption rates vary based on the type of biogas used and the operating conditions.

Q: Can the system be expanded in the future?

A: Yes, the parallel configuration allows for easy scalability. Additional units can be added to increase the overall system capacity, making it ideal for growing businesses or projects with increasing energy demands.
