What is Coalbed Methane (CBM)?
Coalbed Methane (CBM) is a form of natural gas found in coal seams. It is primarily composed of methane and is often released during the mining of coal. CBM is considered a cleaner and more sustainable energy source compared to traditional fossil fuels.
How CBM Gas Generation Works:
CBM Extraction: Methane is extracted from coal seams through drilling techniques.
Power Generation: The extracted methane is used to fuel the 600kW Coalbed Methane Gas Generator, which produces electricity.
Waste Heat Recovery: The generator's by-product heat can be utilized for industrial heating applications.
CBM provides a cleaner alternative to coal combustion and is considered a bridge fuel towards more sustainable energy systems.
Benefits of the 600kW Coalbed Methane Gas Generator
The 600kW Coalbed Methane Gas Generator offers a range of benefits, especially for industries seeking sustainable and cost-effective power solutions:
Environmental Sustainability: By utilizing CBM, a low-carbon energy source, this generator significantly reduces greenhouse gas emissions, particularly methane, which has a much higher global warming potential than CO2.
Cost-Effective Power Generation: CBM is often less expensive than conventional natural gas, making it a cost-effective solution for businesses.
Renewable Energy Source: CBM is considered a renewable resource when compared to fossil fuels, contributing to a more sustainable energy future.
Reduced Environmental Impact: Using CBM to generate electricity helps reduce flaring and venting of methane, which would otherwise contribute to global warming.
Reliable Performance: Built for continuous operation, this generator is designed for efficiency, low downtime, and high reliability in harsh industrial environments.
Main technical features
Turbocharging and shunt Intake technology：
Gas and air will be isolated to eliminate the generation of mixed gas before entering the cylinder with no contact. While the exhaust energy of the generator set is used to turbocharge the gas and air respectively, which realizes the improvement of intake and the synchronous improvement of operation power and volume power and also ensures safety operation.
It has been running safely and steadily for more than 30000 hours since 2018. The measured electric efficiency is more than 40%, that is, one cubic meter of exhaust gas generates one kilowatt-hour of electricity. There is no carbon monoxide leakage, no backfire and flash explosion, and the genset runs smoothly. Self consumption rate is less than 2%. The operation control of the genset is automatically adjusted with the change of gas.
Main technical parameters
| Model | CP22 | CP21 | CP11 |
| CP1500GFW22 | CP1000GFW21 | CP800GFW11 | CP700GFW11 | CP600GFW11 |
| Electrical Output(kw) | 1500 | 1000 | 800 | 700 | 600 |
| Electrical Efficiency(%) | 40 | 40 | 39 | 37.5 | 36.5 |
| Thermal Efficiency(%) | 44 | 44 | 44 | 44 | 43 |
| Total Efficiency(%) | 84 | 84 | 83 | 81.5 | 79.5 |
| Cylinder Number | 16 | 12 | 12 | 12 | 12 |
| Discharge(L) | 110 | 82 | 71.5 | 71.5 | 71.5 |
| Speed(r/min) | 1000 | 1200 | 1000 | 1200 | 1000 | 1200 | 1000 | 1200 | 1000 | 1200 |
| Frequency(Hz) | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 |
| Length(mm) | 8154 | 6920 | 6800 | 6600 | 6600 |
| Width(mm) | 1822 | 2000 | 2000 | 1680 | 1680 |
| Height(mm) | 2125 | 2490 | 2490 | 2490 | 2490 |
| Weight(kg) | 19000 | 15000 | 14000 | 13500 | 13500 |
Applications of the 600kW Coalbed Methane Gas Generator
The 600kW Coalbed Methane Gas Generator is ideal for a variety of industrial applications, especially in regions rich in coal seams with available methane gas resources:
Mining Operations: Utilizes coalbed methane produced during coal mining to generate power, reducing the environmental impact of methane emissions.
Power Generation for Off-Grid Areas: Perfect for remote locations or industrial zones without access to the central power grid.
Energy Recovery from Coal Mines: Helps capture methane from coal mines, reducing the risk of methane-related safety hazards while providing a sustainable energy source.
Industrial Plants and Manufacturing: Provides reliable, cost-effective power for manufacturing plants, processing facilities, and other industrial operations.
Waste-to-Energy Applications: Can be used in landfills or waste treatment facilities where methane is produced, converting waste gases into usable energy.
How the 600kW Coalbed Methane Gas Generator Works
The 600kW Coalbed Methane Gas Generator operates by utilizing the methane extracted from coal seams as fuel. This process provides a continuous, eco-friendly energy source, while also reducing the environmental impact of methane venting or flaring.
Step-by-Step Process:
Methane Extraction: CBM is extracted from underground coal seams using specialized drilling techniques.
Fuel Delivery to the Generator: The extracted methane is delivered to the generator for combustion.
Energy Generation: The generator converts the methane into electrical energy through an internal combustion engine or gas turbine.
Waste Heat Utilization: The waste heat produced during the combustion process can be recovered and used for industrial heating or other applications.
This efficient process makes the 600kW Coalbed Methane Gas Generator an environmentally responsible and cost-effective solution for various industries.
Advantages of Coalbed Methane as a Fuel Source
Coalbed Methane (CBM) is an attractive fuel source for power generation for several reasons:
Cleaner than Traditional Fossil Fuels: CBM combustion produces fewer pollutants than coal or oil, including lower carbon dioxide (CO2) emissions.
Reduced Methane Emissions: Using CBM as a fuel helps prevent methane from being released into the atmosphere, where it can have a much stronger greenhouse effect than CO2.
Lower Fuel Costs: CBM is often more affordable than conventional natural gas, which helps businesses reduce energy expenses.
Improved Safety: By capturing and using methane that would otherwise be vented or flared, CBM helps improve safety in mining operations by reducing the risk of dangerous methane build-up.
Sustainability: CBM is a renewable resource when compared to fossil fuels, contributing to long-term sustainability goals for industries.
Why Choose the 600kW Coalbed Methane Gas Generator?
The 600kW Coalbed Methane Gas Generator stands out as a highly efficient and eco-friendly energy solution:
Low Carbon Emissions: By using CBM, this generator significantly reduces methane emissions, which are potent greenhouse gases.
Cost Savings: CBM is a cost-effective fuel source, which can lead to significant savings in power generation costs compared to conventional fuels.
Environmental Responsibility: Helps industries reduce their environmental footprint by using a sustainable fuel source and minimizing emissions.
Energy Security: Provides a reliable and continuous energy source for industries located near CBM extraction sites, reducing dependence on grid power.
High Reliability: Built for continuous operation in demanding environments, ensuring high efficiency and minimal downtime.
Conclusion: Efficient, Sustainable Power from Coalbed Methane
The 600kW Coalbed Methane Gas Generator provides an efficient, environmentally friendly, and cost-effective solution for industries looking to harness coalbed methane as a fuel source. By converting methane into electricity, this generator helps reduce emissions, lower energy costs, and improve safety in mining and industrial operations. Invest in the 600kW Coalbed Methane Gas Generator today to take advantage of clean energy and reduce your carbon footprint.
