Key Features of the 200kW Cummins Biogas Generator Power Plant
Power Output: The 200kW power output makes this generator ideal for smaller-scale operations requiring continuous, reliable power, such as small manufacturing units, agricultural facilities, or municipal waste treatment plants.
Fuel Type: Designed to run on biogas, the generator converts organic waste into renewable energy, making it an environmentally friendly alternative to conventional fossil fuel-based generators. It can also operate on natural gas, providing flexibility based on fuel availability.
Efficient Energy Conversion: Equipped with advanced Cummins engine technology, the 200kW generator ensures high efficiency in converting biogas into electricity, minimizing fuel consumption while maximizing power output.
Environmentally Friendly: By using biogas as fuel, the generator reduces CO₂ and methane emissions, supporting environmental sustainability goals and helping businesses reduce their carbon footprint.
Compact and Modular Design: The 200kW generator is designed for easy installation and integration into existing infrastructure, making it a cost-effective option for businesses looking to adopt renewable energy without significant upfront investment.
Durability & Reliability: Built with Cummins' renowned engine technology, the generator offers long-term reliability and durability, with minimal downtime and low operational costs.
Product Parameters
AC Alternator data | Gas engine data |
Generator Brand | Stamford | Engine Brand | Cummins |
Motor Model | UCD274K | Engine Model | MNTAA855-N |
Rated Voltage(V) | 415 | Engine type | Inline-6 cylinders-turbocharged |
Rated Power(H class)kW | 200 | Cylinder Bore x Stroke(mm) | 140mm×152mm |
Rated Capacity(H class)kVA | 250 | Displacement (L) | 14 |
Motor efficiency (%)/(400V) | 93.5 | Compression ratio | 11.5 |
Power factor | 0.8 | Rated output power (single) | 265kW-1500rpm/1800rpm |
Connection Methods | D/Y | Maximum lubricant consumption (g/kW.h) | ＜0.3 |
Rotor insulation class | H class | Minimum air intake (kg/h) | 1060 |
Rated temperature rise | F class | Ignition method | Electronically controlled single-cylinder independent high-energyignition |
Excitation method | Brush-less | Fuel Control Method | Equivalent combustion, closed loop control |
Rotation speed (min- 1) | 1500/1800 | Debugging method | Electronic governor |
Shell protection grade | IP23 |
|
|
Applications of the 200kW Cummins Biogas Generator Power Plant
The 200kW Cummins Biogas Generator is perfect for a range of applications, including:
Agricultural Operations: For small to medium farms or agricultural processing plants that produce significant organic waste (e.g., manure, crop residues), the generator can convert waste into electricity, helping to power farm operations and reduce energy costs.
Small-Scale Industrial Operations: Ideal for small factories or manufacturing units, the 200kW generator provides a reliable and affordable power source, reducing dependence on the grid and ensuring stable energy supply even during peak demand periods.
Waste-to-Energy Projects: Municipalities or waste management companies can use the 200kW generator to convert landfill gas or organic waste from local communities into electricity, contributing to cleaner energy generation and waste reduction.
Remote Off-Grid Applications: The generator is suitable for remote areas where access to the grid is limited or unavailable, offering a self-sustaining power solution that utilizes local organic waste for energy production.
How the 200kW Cummins Biogas Generator Power Plant Works
Biogas Production: Organic waste, such as agricultural residues, food waste, or landfill gas, undergoes anaerobic digestion to produce biogas—a mixture of methane and carbon dioxide.
Combustion: The biogas is then fed into the generator’s engine, where it is burned to generate mechanical energy.
Electricity Generation: The mechanical energy is converted into electrical energy, providing reliable power for industrial, agricultural, or municipal applications.
Heat Recovery (Optional): The generator can be equipped with a heat recovery system to capture excess heat, which can be used for heating applications, enhancing overall energy efficiency.
FAQ - 200kW Cummins Biogas Generator Power Plant
1. How often does the 200kW Cummins generator require maintenance?
Routine maintenance is recommended every 2000-3000 operating hours to keep the engine running efficiently, which includes regular checks, oil changes, and air filter replacements.
2. Is this generator suitable for off-grid applications?
Yes, the 200kW Cummins Biogas Generator is ideal for off-grid areas, providing reliable power from local organic waste even in remote locations without access to the grid.
3. What are the key advantages of the 200kW Cummins Biogas Generator?
This generator offers efficient energy conversion, sustainability, low maintenance, and flexible fuel options. It's also compact, making it suitable for smaller applications with moderate power needs.
