Key Features of the 1500kW Weichai Baudouin Biogas Generator
Power Output: Capable of delivering 1500kW of continuous power, this generator is perfect for large-scale energy demands, including industrial plants, large agricultural operations, and municipal waste treatment facilities.
Fuel Type: Runs on biogas, a renewable energy source produced from organic waste, including agricultural residues, landfill gas, and food waste. It is also compatible with natural gas, offering flexibility in fuel choice.
High Fuel Efficiency: With optimized combustion technology, this generator ensures efficient conversion of biogas into electricity, maximizing output while minimizing fuel consumption.
Environmentally Friendly: By using biogas as fuel, the 1500kW generator significantly reduces greenhouse gas emissions compared to traditional fossil fuel-based generators, contributing to cleaner air and a smaller carbon footprint.
Advanced Engine Technology: Powered by Weichai Baudouin engines, known for their reliability, low emissions, and long operational life. These engines are designed to provide superior performance in demanding applications, ensuring long-term reliability with minimal maintenance.
Low Maintenance: Designed for easy maintenance and serviceability, reducing downtime and ensuring a lower total cost of ownership. The generator has high operational uptime with regular maintenance intervals.
Durability & Reliability: Built to last with robust engineering, the Weichai Baudouin generator is designed for high durability and consistent performance, even under harsh operating conditions.
Product Parameters
AC Alternator data | Gas engine data |
Generator Brand | Mecc Alte | Engine Brand | Baudouin |
Motor Model | ECO40-1.5L4B | Engine Model | 12M26D690 |
Rated Voltage(V) | 400 | Engine type | V-12Cylinder-Turbocharged |
Rated Power(H class)kW | 1500 | Cylinder Bore x Stroke(mm) | 150mm×150mm |
Rated Capacity(H class)kVA | 1875 | Displacement (L) | 31.8 |
Motor efficiency (%)/(400V) | 96.8% | Compression ratio | 11 |
Power factor | 0.8 | Rated output power (single) | 1500kW/1500rpm |
Connection Methods | D/Y | Maximum lubricant consumption (g/kW.h) | ＜0.3 |
Rotor insulation class | H class | Minimum air intake (kg/h) | 3012 |
Rated temperature rise | F class | Ignition method | O-Electronically controlled single-cylinder independent high-energy ignition |
Excitation method | Brush-less | Fuel Control Method | Equivalent combustion, closed loop control |
Rotation speed (min- 1) | 1500 | Debugging method | Electronic commissioning |
Shell protection grade | IP23 | Cooling method | Forced water cooling |
Applications of the 1500kW Weichai Baudouin Biogas Generator
The 1500kW Weichai Baudouin Biogas Generator is ideal for a wide range of applications, providing sustainable energy solutions for:
Industrial Operations: For factories and manufacturing plants that require significant energy, this generator can reduce dependence on the grid and lower energy costs.
Municipal Waste Management: Large-scale waste-to-energy projects can benefit from the generator's ability to convert landfill gas or other organic waste into electricity, supporting environmental initiatives and reducing methane emissions.
Large-Scale Farms: Farms that generate large amounts of organic waste, such as animal manure or crop residues, can use the 1500kW generator to produce biogas and power their operations, enhancing sustainability and reducing energy costs.
Biogas Power Plants: Designed for energy companies or operators of biogas power plants, this generator is perfect for large facilities that need reliable and efficient biogas-to-power conversion.
Environmental Benefits of the 1500kW Weichai Baudouin Biogas Generator
Choosing the 1500kW Weichai Baudouin Biogas Generator provides significant environmental advantages:
Carbon Footprint Reduction: Biogas is a cleaner alternative to fossil fuels. By using biogas, businesses can significantly reduce CO₂ emissions and decrease their environmental impact.
Methane Mitigation: Methane, a potent greenhouse gas, is often emitted from landfills and waste treatment facilities. By capturing and converting methane into energy, the 1500kW generator helps reduce these harmful emissions.
Renewable Energy: Biogas is a renewable resource that is replenished by the continuous production of organic waste. Using biogas for power generation supports a circular economy and ensures long-term sustainability.
Compliance with Emission Regulations: The 1500kW generator meets or exceeds international emissions standards, helping companies stay compliant with local and global environmental regulations.
Remarks
1.Engine Control System: ECI (American brand);
2.Throttle: Bosch (German brand);
3.Spark plug: NGK(Japanese brand);
4.Generator master controller: Comap (Czech brand); DEIF(Danish brand); DSE(England brnad);
5.Starting mode: electric start;
6.Overhaul period: 30000h;
7.Generator type: pure copper brushless, automatic voltage regulation;
8.Operation mode: grid-connected/parallel/isolated/automatic control, etc;
Why Choose the 1500kW Weichai Baudouin Biogas Generator?
Superior Performance: With 1500kW of power output, this generator is designed for large-scale operations, ensuring a stable and continuous power supply for demanding applications.
High Efficiency: The advanced engine technology from Weichai Baudouin optimizes biogas combustion, ensuring maximum electricity output with minimal fuel use.
Environmental Responsibility: The use of biogas helps lower CO₂ and methane emissions, supporting a more sustainable energy solution and reducing your carbon footprint.
Flexibility: With the ability to run on both biogas and natural gas, this generator offers operational flexibility, making it easier to adapt to changing fuel availability and prices.
Low Operating Costs: Due to its high efficiency and low maintenance needs, the 1500kW Weichai Baudouin Biogas Generator is a cost-effective power solution with a long operational life.
Durability & Reliability: Designed to withstand the rigors of large-scale industrial and municipal applications, the generator is built to last with minimal downtime.
FAQ - 1500kW Weichai Baudouin Biogas Generator
1. How much power does the 1500kW Weichai Baudouin Biogas Generator produce?
The generator produces 1500kW of continuous power, making it suitable for large-scale operations, such as industrial plants, large farms, and municipal waste-to-energy projects.
2. Can the 1500kW Weichai Baudouin Biogas Generator run on natural gas?
Yes, the generator is capable of running on both biogas and natural gas, providing flexibility in fuel selection based on availability and cost.
3. What are the environmental benefits of using biogas for power generation?
Biogas is a cleaner fuel alternative to fossil fuels. By using biogas, you reduce CO₂ emissions, decrease reliance on non-renewable energy, and help mitigate methane emissions, which are harmful greenhouse gases.
4. What is the maintenance schedule for the 1500kW Weichai Baudouin Biogas Generator?
Routine maintenance is recommended every 3000 operating hours. This includes oil changes, air filter replacements, and system checks to ensure optimal performance.
