What is Coalbed Methane (CBM)?
Coalbed Methane (CBM) is a form of natural gas extracted from coal seams. It consists primarily of methane gas and is often released during coal mining operations. Historically, methane was vented or flared, but today, it can be captured and used as a clean, renewable fuel for power generation.
How CBM Gas Generation Works:
Methane Extraction: Methane is extracted from coal seams through drilling techniques.
Fuel Supply: The extracted methane is supplied to the 1000kW Silent-Type Coalbed Methane Gas Generator for combustion.
Electricity Generation: The combustion process generates mechanical energy, which is then converted into electricity by the generator’s engine or turbine.
Heat Recovery: Waste heat from the combustion process can be utilized for other industrial heating needs, improving overall energy efficiency.
Utilizing CBM for power generation reduces greenhouse gas emissions and offers a cleaner energy solution compared to conventional fossil fuels.
Benefits of the 1000kW Silent-Type Coalbed Methane Gas Generator
The 1000kW Silent-Type Coalbed Methane Gas Generator offers numerous benefits that make it an ideal choice for industries looking for sustainable, cost-effective, and low-noise power generation solutions:
Silent Operation: Designed for noise-sensitive environments, this generator operates quietly, making it ideal for locations where noise reduction is essential, such as residential areas, hospitals, and office buildings.
Reduced Methane Emissions: By capturing and utilizing methane, this generator prevents the release of this potent greenhouse gas into the atmosphere, contributing to a cleaner environment.
Cost-Effective: CBM is often less expensive than conventional natural gas, which helps businesses lower their energy costs.
Renewable Energy Source: CBM is a renewable resource, making it a long-term, sustainable energy solution.
High Reliability and Efficiency: The generator is built for high efficiency, providing reliable, continuous power for industrial applications while minimizing fuel consumption.
Main technical features
Turbocharging and shunt Intake technology：
Gas and air will be isolated to eliminate the generation of mixed gas before entering the cylinder with no contact. While the exhaust energy of the generator set is used to turbocharge the gas and air respectively, which realizes the improvement of intake and the synchronous improvement of operation power and volume power and also ensures safety operation.
It has been running safely and steadily for more than 30000 hours since 2018. The measured electric efficiency is more than 40%, that is, one cubic meter of exhaust gas generates one kilowatt-hour of electricity. There is no carbon monoxide leakage, no backfire and flash explosion, and the genset runs smoothly. Self consumption rate is less than 2%. The operation control of the genset is automatically adjusted with the change of gas.
Main technical parameters
| Model | CP22 | CP21 | CP11 |
| CP1500GFW22 | CP1000GFW21 | CP800GFW11 | CP700GFW11 | CP600GFW11 |
| Electrical Output(kw) | 1500 | 1000 | 800 | 700 | 600 |
| Electrical Efficiency(%) | 40 | 40 | 39 | 37.5 | 36.5 |
| Thermal Efficiency(%) | 44 | 44 | 44 | 44 | 43 |
| Total Efficiency(%) | 84 | 84 | 83 | 81.5 | 79.5 |
| Cylinder Number | 16 | 12 | 12 | 12 | 12 |
| Discharge(L) | 110 | 82 | 71.5 | 71.5 | 71.5 |
| Speed(r/min) | 1000 | 1200 | 1000 | 1200 | 1000 | 1200 | 1000 | 1200 | 1000 | 1200 |
| Frequency(Hz) | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 |
| Length(mm) | 8154 | 6920 | 6800 | 6600 | 6600 |
| Width(mm) | 1822 | 2000 | 2000 | 1680 | 1680 |
| Height(mm) | 2125 | 2490 | 2490 | 2490 | 2490 |
| Weight(kg) | 19000 | 15000 | 14000 | 13500 | 13500 |
Advantages of Using Coalbed Methane for Power Generation
Using Coalbed Methane (CBM) as a fuel source offers several advantages over traditional fossil fuels:
Cleaner than Coal: CBM combustion produces fewer pollutants, such as sulfur dioxide, carbon dioxide, and particulates, compared to coal and oil.
Reduced Methane Emissions: By capturing and using methane, this generator helps prevent the release of this potent greenhouse gas into the atmosphere.
Cost-Effective: CBM is generally cheaper than natural gas, making it a cost-effective fuel for power generation.
Sustainable Energy Source: As a renewable resource, CBM provides a long-term, sustainable solution for power generation.
Improved Safety: Using CBM helps reduce the risk of methane buildup in coal mines, improving safety in mining operations.
Why Choose the 1000kW Silent-Type Coalbed Methane Gas Generator?
The 1000kW Silent-Type Coalbed Methane Gas Generator is the perfect solution for businesses looking for a clean, quiet, and reliable power source. Here’s why it stands out:
Silent Operation: The generator’s advanced noise reduction technology ensures quiet operation, making it suitable for noise-sensitive areas.
Environmental Responsibility: Utilizing CBM reduces the environmental impact by capturing methane that would otherwise be released into the atmosphere.
Cost Savings: CBM is often less expensive than conventional natural gas, helping to lower energy costs for industrial applications.
Renewable and Sustainable: CBM is a renewable fuel, providing long-term, eco-friendly energy for industries.
High Reliability and Efficiency: Designed for continuous operation with high efficiency, this generator ensures a steady power supply with minimal fuel consumption.
Conclusion: A Quiet, Clean, and Efficient Power Solution
The 1000kW Silent-Type Coalbed Methane Gas Generator offers a powerful, sustainable, and cost-effective solution for industries seeking a quiet and eco-friendly energy source. By utilizing coalbed methane, this generator reduces greenhouse gas emissions, lowers energy costs, and provides reliable power for various industrial applications. Choose the 1000kW Silent-Type Coalbed Methane Gas Generator for an efficient, low-noise power generation solution.
